Wetting & Balance Test
The wetting & balance test is a critical quality control method used to evaluate the wetting performance of solder and substrates during the soldering process. It finds wide application in electronic manufacturing, semiconductor packaging, and Printed Circuit Board (PCB) production. By measuring the change in contact angle between solder and substrate surfaces during heating, the wetting & balance test provides crucial information about solder wetting performance and solder joint quality, ensuring essential support for the reliability and performance of electronic products.
Basic Principles and Importance of Wetting & Balance Test
The wetting & balance test is based on the wetting behavior of solder on substrate surfaces during heating. After melting, the solder contacts the substrate surface, forming a specific contact angle. By measuring changes in this contact angle, the wetting performance of the solder can be evaluated. A smaller contact angle indicates better wetting performance, and vice versa.
Wetting performance is crucial for the soldering quality of electronic components and PCBs. Good wetting performance ensures the mechanical strength of solder joints and the reliability of electrical connections, avoiding soldering defects such as voids, cracks, and cold joints. In high-reliability applications such as aerospace and medical devices, the wetting & balance test provides significant quality assurance, ensuring product stability and performance in harsh environments.
Process of Wetting & Balance Test
Test Preparation:
● Define testing objectives and requirements, and select appropriate wetting & balance test equipment and parameters.
● Prepare test samples, ensuring clean and oxide-free sample surfaces for optimal test results.
Sample Loading:
● Secure solder and substrate samples on testing equipment to ensure stability and proper positioning.
● Load samples into the testing environment to set heating temperature and duration.
Wetting Measurement:
● Heat solder to melt and contact with substrate surfaces.
● Use measurement equipment to monitor real-time changes in contact angle between solder and substrate, recording force balance data during the wetting process.
Data Analysis:
● Utilize specialized software to process and analyze wetting & balance test data, and calculate solder wetting force and contact angle changes.
● Combine experimental parameters to evaluate solder wetting performance and solder joint quality.
Report Preparation and Results Interpretation:
● Thoroughly document test results, including wetting force curves and contact angle change graphs.
● Prepare detailed wetting & balance test reports for subsequent quality control and improvement references.
Wetting & Balance Test Equipment
● Wetting & Balance Testers: High-precision equipment used to measure solder wetting performance on substrates. Commonly used testers include dynamic wetting balance instruments and static contact angle measurement devices.
● Heating Systems: Provide stable heating environments to ensure solder melts and contacts substrates at set temperatures.
● Data Acquisition Systems: Used for real-time monitoring and recording of force balance data and contact angle changes during wetting.
● Specialized Analysis Software: Used to process and analyze wetting & balance test data, generating wetting force and contact angle change graphs.
In our laboratory, the wetting & balance test is a crucial tool to ensure the soldering quality and reliability of electronic products. By employing advanced wetting & balance test equipment and technology, we provide precise and comprehensive analysis of solder wetting performance for our clients. This not only helps identify and avoid potentially defective materials but also enhances overall product reliability and market competitiveness. Our wetting & balance test services enable clients to confidently select and use the highest quality soldering materials and processes, thereby achieving superior product performance and safety.
